CROSBY
When you are buying Crosby, you are buying more than a product.
you are buying quality
BB Lifting made the professional choice to use Crosby fittings for wire rope terminations. Heavy lift slings manufactured by BB Lifting are made with Flemish Spliced, complete with the Crosby S-505 Steel Sleeves. S-505 Steel Sleeve rope terminations are available from 10mm to 115mm rope diameter. Crane boom Pennants are also terminated with Crosby Swaged Sockets.
Crosby iP, Lifting Clamps
We supply horizontal and vertical plate lifting clamps, beam clamps, pipe and drum clamps, etc. |
|
Screw Pin Anchor Shackles
G-209
Screw pin anchor shackles meet the performance requirements of Federal Specification RR-C-271D Type IVA, Grade A, Class 2, except for those provisions required of the contractor.
G-210
Screw pin chain shackles meet the
performance requirements of Federal Specification RR-C-271D, Type IVB,Grade A, Class 2, except for those provisions required of the contractor.
Screw Pin Chain Shackles
G-2130 Screw Pin Chain shackles with thin
head bolt - nut with cotter pin. Meets the
performance requirements of Federal
Specification RR-C-271D Type IVA,
Grade A, Class 3, except for those provisions required of the contractor.
Bolt Type Chain Shackles
G-2150
Bolt Type Chain shackles. Thin hex head
bolt - nut with cotter pin. Meets the
performance requirements of Federal
Specification RR-C271D Type IVB, Grade
A, Class 3, except for those provisions
required of the contractors.
Alloy Bolt Type Anchor Shackles
G-2140
Wide Body Shackles
G-2160
Bolt Type Chain shackles. Thin hex head
bolt - nut with cotter pin. Meets the
performance requirements of Federal
Specification RR-C271D Type IVB, Grade
A, Class 3, except for those provisions
required of the contractors.
|
Features
• Capacities 1/3 thru 55 metric tons.
• Working Load Limit permanently shown on every shackle.
• Forged — Quenched and Tempered, with alloy pins
• Hot Dip galvanized or Self Colored.
• Fatigue rated (1/3t - 55t).
• Shackles 25t and larger are RFID EQUIPPED.
• Shackles can be furnished proof tested with certificates to designated standards, such as ABS, DNV, Lloyds, or other certification. Charges for proof testing and certification available when requested at the time of order.
• Shackles are Quenched and Tempered and can meet DNV impact requirements of 42 joules at -20 C.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by
ASME B30.26.
download PDF for more details
back to top
Features
• Capacities 1/3 thru 150 metric tons.
• Forged - Quenched and Tempered, with alloy pins.
• Hot Dip galvanized or Self Colored.
• Fatigue rated
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• Shackles 55 metric tons and smaller can be furnished proof tested with certificates to designated standards, such as ABS, DNV, Lloyds, or other certification when requested at time of order.
• Shackles 85 metric tons and larger can be provided as follows.
• Non Destructive Tested
• Serialized Pin and Bow
• Material Certification (Chemical)
download PDF for more details
back to top
Features
• Capacities 1/3 thru 150 metric tons.
• Forged - Quenched and Tempered, with
alloy pins.
• Hot Dip galvanized or Self Colored.
• Fatigue rated
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• Shackles 55 metric tons and smaller can be furnished proof tested with certificates to designated standards, such as ABS, DNV, Lloyds, or other certification when requested at time of order.
• Shackles 85 metric tons and larger can be provided as follows.
• Non Destructive Tested
• Serialized Pin and Bow
• Material Certification (Chemical)
download PDF for more details
back to top
Features
• Can be used to connect HIGH STRENGTH Synthetic Web Slings, HIGH STRENGTH Synthetic Round Slings or Wire Rope Slings.
• Increase in shackle bow radius provides minimum 58% gain in sling bearing surface and eliminates need for a thimble.
Increases usable sling strength minimum of 15%.
• Pin is non-rotating, with weld -on handles for easier use (300t and larger).
• All 2160 shackles are individually proof tested and magnetic particle inspected. Crosby certification available at time of order
download PDF for more details
back to top
download PDF for more details
back to top |
|
Open Grooved Sockets
G-416
Open Grooved Sockets meet the
performance requirements of FederalSpecification RR-S-550D, Type A, except for those provisions required of the contractor
Closed Grooved Sockets
G-417 Closed grooved Sockets meet the
performance requirements of Federal Specification RR-S-550D, Type B, except for those provisions required of the contractor.
M-Line" Mooring Sockets
G-517
|
FEATURES
• Forged Steel Sockets thru 1-1/2", cast alloy steel 1-5/8" thru 4".
• Spelter socket terminations have an efficiency rating of 100%,based on the catalog strength of wire rope. Ratings are based on recommended use with 6 x 7, 6 x 19, or 6 x 37, IPS or XIP (EIP), XXIP (EEIP), RRL, FC, or IWRC wire rope.
NOTICE:
All cast steel sockets 1-5/8" and larger are magnetic particle inspected and ultrasonic inspected. Proof testing available on special order.
download PDF for more details
back to top
FEATURES
• Forged Steel Sockets thru 1-1/2", cast alloy steel 1-5/8" thru 4".
• Spelter socket terminations have an efficiency rating of 100%,based on the catalog strength of wire rope. Ratings are based on recommended use with 6 x 7, 6 x 19, or 6 x 37, IPS or XIP (EIP),
XXIP (EEIP), RRL, FC, or IWRC
wire rope.
NOTICE:
All cast steel sockets 1-5/8" and larger are magnetic particle inspected and ultrasonic inspected. Proof testing available on special order.
download PDF for more details
back to top
FEATURES
• Wide range of sizes available
• 1-1/4" thru 4" Wire Line
• "M-Line" socket terminations have a 100% efficiency rating, based on the
catalog strength of the wire rope.
• Galvanized finish
• Designed for today's higher strength classes of wire rope.
• Design of bail allows for easy connection to shackles and other connecting links.
• Socket design utilizes features to keep cone from rotating.
• Spelter socket terminations have an efficiency rating of 100%, based on the catalog strength of wire rope. Ratings are based on recommended use with 6 x 7, 6 x 19, or 6 x 37, IPS or XIP (EIP), XXIP (EEIP), RRL, FC, or IWRC wire rope.
download PDF for more details
back to top
|
|
|
|
Hook & Hook Turnbuckles
HG-223
|
• End fittings are Quenched and Tempered, bodies heat treated by normalizing.
• Hot Dip galvanized steel.
• Hooks are forged with a greater cross sectional area that results in a stronger hook with better fatigue properties.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
• Modified UNJ thread on end fittings for improved fatigue properties.
• Body has UNC threads.
• Lock Nuts available for all sizes.
• Fatigue Rated.
download PDF for more details
back to top
|
|
|
|
Hook & Hook Turnbuckles
HG-225
|
• End fittings are Quenched and Tempered, bodies heat treated by normalizing.
• Hot Dip galvanized steel.
• Turnbuckle eyes are forged elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckles sizes 1/4" through 1", a shackle one size smaller can be reeved through eye.
• Turnbuckle hooks are forged with a greater cross sectional area that results in a stronger hook with better fatigue properties.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
• Modified UNJ thread on end fittings for improved fatigue properties.
• Body has UNC threads.
• Lock Nuts available for all sizes.
• Fatigue Rated
download PDF for more details
back to top
|
|
|
|
Eye & Eye Turnbuckles
HG-226 |
• End fittings are Quenched and Tempered, bodies heat treated by normalizing.
• Hot Dip galvanized steel.
• Turnbuckle eyes are forged elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckle sizes 1/4" through 2-1/2", a shackle one size smaller can be reeved through eye.
• Modified UNJ thread on end fittings for improved fatigue properties. Body has UNC
threads.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
• Lock Nuts available for all sizes.
• Fatigue Rated
download PDF for more details
back to top
|
|
|
|
Jaw & Eye Turnbuckles
HG-227 |
• End fittings are Quenched and Tempered, bodies heat treated by normalizing.
• Hot Dip galvanized steel.
• Turnbuckles eyes are forged and elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckles size 1/4" through 2-1/2", a shackle one size smaller can be reeved through eye.
• Forged jaw ends are fitted with bolts and nuts for 1/4" through 5/8", and pins and cotters on 3/4" through 2-3/4" sizes.
• Modified UNJ thread on end fittings for improved fatigue properties.
• Body has UNC threads.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26
• TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
• Lock Nuts available for all sizes.
• Fatigue Rated.
download PDF for more details
back to top
|
|
|
|
Jaw & Jaw Turnbuckles
HG-228 |
• End fittings are Quenched and Tempered, bodies heat treated by normalizing.
• Hot Dip galvanized steel.
• TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
• Forged jaw ends are fitted with bolts and nuts for 1/4" through 5/8", and pins and cotters on 3/4" through 2-3/4" sizes.
• Modified UNJ thread on end fittings for improved fatigue properties.
• Body has UNC threads.
• Crosby products meet or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, Crosby products meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• Lock Nuts available for all sizes
• Fatigue Rated
download PDF for more details
back to top
|
|
